Key Features

Ethernet port

100/10Mb Ethernet port

Optional Wi-Fi port

supports WEP/WPA/WPA2 security

IP Configuration

Static IP or IP configuration via DHCP

IO and sensing functionality

Digital IO lines (3.3V logic levels with 5V tolerance)

Optically isolated inputs (several configurations)

Open-collector outputs (several configurations)

Mechanical relays (low-current, high-current, and high-voltage options)

Solid-state relays (SSRs)

Pulse-width modulated (PWM) outputs (several configurations)

Temperature, humidity, pressure, light, and 3-axis acceleration sensors

Digital potentiometers of several nominals

8-line extension port (3.3V logic levels)

Analog-to-digital converters with voltage input

Digital-to-analog converter with voltage output

RTD and thermocouple temperature meters

RS485 port for connecting RS485 Modbus Sensors (Bus Probes)

Button and LED indicators

External sensors

Ambient temperature sensor

Ambient temperature and humidity sensor

Ambient light sensor

Acceleration and tilt angle sensor

Configuration

Full configuration via advanced web interface

Monitoring

Modbus protocol, SNMP protocol

Power

12V or 24V, optional: PoE power
